Explicit

Data Structures
class	model::FDModel< T >
	A class for finite difference approximation of Peridynamics More...
class	model::QuasiStaticModel< T >
	A class for finite difference approximation of Peridynamics More...

Functions
void	model::QuasiStaticModel< T >::assembly_jacobian_matrix ()
	Assembles the Jacobian matrix.
void	model::QuasiStaticModel< T >::assembly_jacobian_matrix_part (size_t begin, size_t end, size_t thread)
	Assembles the Jacobian matrix. More...
void	model::QuasiStaticModel< T >::computeForces (bool full=false)
	Computes the forces of all nodes. More...
void	model::QuasiStaticModel< T >::computePertubatedForces (size_t thread)
	Computes the forces of all nodes using the perturbed displacement. More...
util::VectorXi	model::QuasiStaticModel< T >::computeResidual ()
	Computes the residual for the Newton step. More...
void	model::QuasiStaticModel< T >::initHObjects ()
	Initialize all data members.
util::VectorXi	model::QuasiStaticModel< T >::newton_step (util::VectorXi &res)
	Computes the new displacement of Newton step. More...
	model::QuasiStaticModel< T >::QuasiStaticModel (inp::Input *deck)
	Constructor. More...
void	model::QuasiStaticModel< T >::solver ()
	Starts the simulation and controls the solver.
	model::QuasiStaticModel< T >::~QuasiStaticModel ()
	Destructor.

Variables
data::DataManager *	model::QuasiStaticModel< T >::d_dataManager_p
	Data Manager.
std::vector< data::DataManager * >	model::QuasiStaticModel< T >::d_dataManagers
	Data manager objects for the assembly of the stiffness matrix.
inp::Input *	model::QuasiStaticModel< T >::d_input_p
	Pointer to Input object.
material::pd::BaseMaterial *	model::QuasiStaticModel< T >::d_material_p
	Pointer to Material object.
inp::ModelDeck *	model::QuasiStaticModel< T >::d_modelDeck_p
	Model deck.
std::string	model::QuasiStaticModel< T >::d_name
	Name of the model.
size_t	model::QuasiStaticModel< T >::d_nnodes
	Number of nodes.
size_t	model::QuasiStaticModel< T >::d_osThreads
	Number of available os threads.
inp::OutputDeck *	model::QuasiStaticModel< T >::d_outputDeck_p
	Output deck.
double	model::QuasiStaticModel< T >::d_time
	Current simulation time.
util::Matrixij	model::QuasiStaticModel< T >::jacobian

Functions to manipulate the tangent stiffness matrix
void	model::QuasiStaticModel< T >::removeRow (util::Matrixij &matrix, size_t rowToRemove)
	Removes the i-th row of a matrix. More...
void	model::QuasiStaticModel< T >::removeCol (util::Matrixij &matrix, size_t colToRemove)
	Removes the i-th column of a matrix. More...
void	model::QuasiStaticModel< T >::removeRow (util::VectorXi &vector, size_t rowToRemove)
	Removes the i-th row of a vector. More...

Detailed Description

Function Documentation

assembly_jacobian_matrix_part()

template<class T >

void model::QuasiStaticModel< T >::assembly_jacobian_matrix_part ( size_t  begin, size_t  end, size_t  thread  )

inlineprivate

Assembles the Jacobian matrix.

Parameters

begin	First node of the chunk
end	Last node of the chunk
thread	Id of the thread handling this chunk

computeForces()

template<class T >

void model::QuasiStaticModel< T >::computeForces ( bool  full = false )

private

Computes the forces of all nodes.

Parameters

full	If true the Strain and Stress tensors are computed

computePertubatedForces()

template<class T >

void model::QuasiStaticModel< T >::computePertubatedForces ( size_t  thread )

inlineprivate

Computes the forces of all nodes using the perturbed displacement.

Parameters

thread

The thread which is doing the actual computation

Here is the call graph for this function:

computeResidual()

template<class T >

util::VectorXi model::QuasiStaticModel< T >::computeResidual

private

Computes the residual for the Newton step.

Returns

The residual vector

newton_step()

template<class T >

util::VectorXi model::QuasiStaticModel< T >::newton_step ( util::VectorXi &  res )

private

Computes the new displacement of Newton step.

Parameters

res	Residual vector

Returns

The updated displacement

QuasiStaticModel()

template<class T >

model::QuasiStaticModel< T >::QuasiStaticModel

(

inp::Input *

deck

)

Constructor.

Parameters

deck	Pointer to the input deck

Here is the call graph for this function:

removeCol()

template<class T >

void model::QuasiStaticModel< T >::removeCol ( util::Matrixij &  matrix, size_t  colToRemove  )

private

Removes the i-th column of a matrix.

Parameters

matrix	The matrix
colToRemove	Id of the column to remove

removeRow() [1/2]

template<class T >

void model::QuasiStaticModel< T >::removeRow ( util::Matrixij &  matrix, size_t  rowToRemove  )

private

Removes the i-th row of a matrix.

Parameters

matrix	The matrix
rowToRemove	Id of the row to remove

removeRow() [2/2]

template<class T >

void model::QuasiStaticModel< T >::removeRow ( util::VectorXi &  vector, size_t  rowToRemove  )

private

Removes the i-th row of a vector.

Parameters

vector	The vector
rowToRemove	Id of the row to remove

Variable Documentation

jacobian

template<class T >

util::Matrixij model::QuasiStaticModel< T >::jacobian

private

Jacobian matrix
